9-Port Unmanaged Desktop Switch with 8 Port PoE PFS3009-8ET1GT-96-V2

Product reference: KSPFS3009-8ET1GT96V2
  • The parameters and datasheets below can only be applied to V2.0 (version 2.0)
  • Intelligent PoE
  • BT 90W
  • 8-pin assignment PoE power supply
  • Long distance PoE
  • PoE watchdog
  • Wide working temperature

Read more
At stores prices may vary
Price:
€72.60
€60.00 tax excl.

Product information

9-Port Unmanaged Desktop Switch with 8 Port PoE

Hardware

Data Transmission Port

Port 1–8: 8 × RJ-45 10/100 Mbps (PoE)

Port 9: 1 × RJ-45 10/100/1000 Mbps (Uplink)

Power Supply

48 V - 57 V DC

Operaing Temperature

–10 °C to +55 °C (+14°F to +131°F)

Operating Humidity

5% – 95% (RH)

Storage Temperature

–20 °C to +70 °C (–4°F to +158°F)

Storage Humidity

5% – 95% (RH)

Power Consumption

Idling: 3 W

Full load: 96 W

Performance

Capacity

3.6 Gbps

Packet Forwarding Rate

2.678 Mbps

Packet Buffer Memory

1 Mbit

MAC Table Size

2K

Communication Standard

IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x

PoE

PoE Standard

IEEE802.3af/ IEEE802.3at/ Hi-PoE/ IEEE802.3bt

PoE Power

96W

Power Consumption Management

Yes

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE

250 m long distance PoE transmission

General

Statics Protection

Air discharge: 8 kV
Contact discharge: 6 kV

Thunder-proof

Common mode: 4kV
Differential mode: 2kV

Net Weight

0.47 kg (1.03 lb)

Gross Weight

1.32 kg (2.91 lb)

Product Dimensions

190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18")

Features

Incoming Bandwidth 10/100/1000
Ports 9
PoE ports 8
